Philips 86" Qline UHD Commercial Display

Product Code: 86BDL3511Q

Share this product
Unit Description
Each
Usually Ships 5-7 Days
Login for School Account Pricing

$3480.49 inc GST
Increase value Decrease value
Quantity in cart:
Qty Each Save %
  • Description
  • Specifications
  • Contact Us

Signage Solutions Q-Line Display

Stand out
Inform and enthrall with a Philips Q-Line Professional Ultra HD Display. This reliable solution can be up and running as quickly as you need.

Easy-setup 18/7 display.

  • 86"
  • Ultra HD
  • Direct LED Backlight

Operate, monitor and maintain with CMND & Control
Run your display network over a local (LAN) connection. CMND & Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.

FailOver ensures content is always playing
From waiting room to meeting room, never show a blank screen. FailOver lets your Philips Professional Display switch automatically between primary and secondary inputs ensuring content keeps playing even if the primary source goes down. Simply set a list of alternate inputs to be sure your business is always on.

Schedule what you want, when you want with SmartPlayer
Turn your USB into a true cost effective digital signage device. Simply save your content (video, audio, pictures) on your USB and plug into your display.Create your playlist and schedule your content via the on screen menu, and enjoy your own created playlists anytime, anywhere.

Integrated media player. Easily schedule USB content
Easily schedule content to play from USB. Your Philips Professional Display will wake from standby to play the content you want, and then return to standby once playback is done.


ZPW86BDL3511Q

Connectivity

  • Audio output: 3.5mm jack
  • Video input:
    • DVI-I (x 1)
    • HDMI 2.0 (x3)
    • USB 2.0 (x2)
  • Audio input: 3.5 mm jack
  • Other connections: OPS
  • External control:
    • IR (in/out) 3.5 mm jack
    • RJ45
    • RS232C (in/out) 2.5 mm jack

Picture/Display

  • Diagonal screen size (metric): 217.4  cm
  • Aspect ratio: 16:9
  • Panel resolution: 3840 x 2160
  • Pixel pitch: 0.4935 x 0.4935 mm
  • Optimum resolution: 3840 x 2160 @ 60 Hz
  • Brightness: 400 cd/m²
  • Display colours: 1.07 Billion
  • Contrast ratio (typical): 1200:1
  • Dynamic contrast ratio: 500,000:1
  • Response time (typical): 8 ms
  • Viewing angle (horizontal): 178 degree
  • Viewing angle (vertical): 178 degree
  • Panel technology: IPS
  • Clinical image: D-Image preset (dicom part 14 compatible)
  • Haze: 25%

Convenience

  • Placement:
    • Landscape (18/7)
    • Portrait (18/7)
  • Tiled Matrix: Up to 10 x 15
  • Keyboard control:
    • Hidden
    • Lockable
  • Remote control signal: Lockable
  • Signal loop through:
    • RS232
    • IR Loopthrough
  • Ease of installation: Smart Insert
  • Energy saving functions: Smart Power
  • Network controllable:
    • RS232
    • RJ45
  • Start-up:
    • Switch on delay
    • Switch on status
    • Boot on source
  • Start-up window: enable / disable Philips logo

Sound

  • Built-in speakers: 2 x 10W RMS

Power

  • Mains power: 100 - 240V~, 50/60Hz
  • Consumption (Typical): 360 W
  • Consumption (Max): 500 W
  • Standby power consumption: <0.5 W
  • Power Saving Features: Smart Power
  • Energy Label Class: G

Supported Display Resolution

Computer formats:

  • 640 x 480, 60, 67, 72, 75Hz
  • 720 x 400, 70Hz
  • 800 x 600, 56, 60, 72, 75Hz
  • 832 x 624, 75Hz
  • 1024 x 768, 60, 70, 75Hz
  • 1152 x 864, 75Hz
  • 1152 x 870, 75Hz
  • 1280 x 720, 60Hz
  • 1280 x 800, 60Hz
  • 1280 x 1024, 60Hz
  • 1440 x 900, 60Hz
  • 1600 x 1200, 60Hz
  • 1680 x 1050, 60Hz
  • 1920 x 1080, 60Hz
  • 3840 x 2160, 30, 60Hz

Video formats

  • 480i, 60Hz
  • 480p, 60Hz
  • 576p, 50Hz
  • 576i, 50Hz
  • 720p, 60Hz
  • 1080i, 50, 60Hz
  • 1080p, 50, 60Hz
  • 3840 x 2160, 30Hz
  • 3840 x 2160, 60Hz

Dimensions

  • Set Width: 1929.0  mm
  • Product weight: 49.5  kg
  • Set Height: 1100.0 mm
  • Set Depth: 69.5mm(D@wall mount) / 91.8mm(D@handle)  mm
  • Wall Mount: 600mm x 400mm , M8
  • Bezel width: 15.5 mm (Even bezel)

Operating conditions

  • Altitude: 0 ~ 3000 m
  • Temperature range (operation): 0 ~ 40  °C
  • MTBF: 50,000  hour(s)
  • Temperature range (storage): -20 ~ 60  °C
  • Humidity range (operation)[RH]: 20 ~ 80% RH (No condensation)
  • Humidity range (storage) [RH]: 5 ~ 95% RH (No condensation)

Multimedia Applications

USB Playback Video

  • H.264
  • JPEG
  • MPEG
  • WMV3

USB Playback Picture

  • BMP
  • JPEG
  • PNG

USB Playback Audio

  • AAC
  • WMA
  • MPEG
  • HEAAC
Captcha Image
Signature
Product Specifications
Product Type Commercial Display
Brand Philips
Size 86"
Warranty Information
3 Year Warranty
